Information

Maxsym 400i, a combination of extraordinary engine power and artistic integral design, incarnates the consummate technology of SYM. The sharp dual projection headlights are of excellent aggression and safety. The excellent ergonomic setting offers outstanding comfort for long-distance cruising. SYM is proud to present this masterpiece, which offers dynamic, safe, and comfortable ride in and out the city.

COLOR

Specifications

OverallLength (mm)2270OverallWidth (mm)825
OverallHeight (mm)1410SeatHeight755
WheelBase (mm)1555GroundClearance (mm)142
WeightFront (kg)94WeightRear (kg)135
SpecsWeight (kg)229TransmissionC.V.T., auto speed change
PrimaryReductionbelt, 2.23~ 0.75FinalReductiongear, 7.21
EngineType4-stroke,4V,water cooledCylindersingle cylinder
Displacement399FuelSystemEFI(C.L.)
FuelControlO.H.C.MaxHorsepower24.5Kw/7000rpm
MaxTorque34.5Nm/5500rpmFuelTypeunlead gasoline
ExhaustEmissionCo< 2.0ExhaustEmissionHC< 0.3
ExhaustEmissionHCNOx< 0.15Noise (dB)< 80
Alternator338 W / 5000 rpmBatteryVoltage12 V 11.2Ah
HeadlightLamp12 V 55W / 55W× 2FrontPositionLampLED
TaillightStoplightLampLEDFrontTurningSignalLight12 V 10W× 2
RearTurningSignalLight12 V 10W× 2LicensePlateLamps12 V 5W× 1
RearReflector1FrameTypepipe under bone
FrameMaterialsteelFrontSuspensiontelescopic fork
RearSuspensionunit swingFrontRimaluminum
RearRimaluminumFrontTireTypetubeless
FrontTireDimensions120 / 70 – R15 56SRearTireTypetubeless
RearTireDimensions160 / 60 – R14 65HFrontBrakesdouble disk
FrontBrakeDiameter (mm)φ275× 2RearBrakesdisk
RearBrakeDiameter (mm)φ275FuelCapacity (l)14.2
MaxSpeed143FuelConsumption (km/l)> 25
ClimbingCapacity (deg)> 24
